| What is the body type, Volkswagen Transporter (T5, facelift 2009) Kombi? | Van, 4-5 Doors, 4-9 Seats |
|---|---|
| What is the fuel economy, Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 (116 Hp) L1H2? | 10.4 l/100 km 22.62 US mpg 27.16 UK mpg 9.62 km/l |
| How ECO is the car, Volkswagen Transporter 2.0 (116 Hp) L1H2? | 243 g/km CO2 Euro 5 |
| How fast is the car, 2009 Transporter (T5, facelift 2009) Kombi 2.0 (116 Hp) L1H2? | 158 km/h | 98.18 mph 0-100 km/h: 16.6 sec 0-60 mph: 15.8 sec |
| How much power, Volkswagen Transporter Van 2009 2.0 (116 Hp) L1H2? | 116 Hp, 170 Nm 125.39 lb.-ft. |
| What is the engine size, Volkswagen Transporter Van 2009 2.0 (116 Hp) L1H2? | 2.0 l 1984 cm3 121.07 cu. in. |
| How many cylinders, 2009 Volkswagen 2.0 (116 Hp) L1H2? | 4, Inline |
| What is the drivetrain, Volkswagen Transporter (T5, facelift 2009) Kombi Van 2009 2.0 (116 Hp) L1H2? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2009 Volkswagen Transporter Van? | 4892 mm 192.6 in. |
| How wide is the vehicle, 2009 Volkswagen Transporter Van? | 1904 mm 74.96 in. |
| What is the curb weight, 2009 Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 (116 Hp) L1H2? | 1901-2029 kg 4190.99 - 4473.18 lbs. |
| What is the gross weight, 2009 Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 (116 Hp) L1H2? | 2850 kg 6283.17 lbs. |
| How much trunk (boot) space, 2009 Volkswagen Transporter Van? | 6700 l 236.61 cu. ft. |
| How many gears, What type is the gearbox, 2009 Volkswagen Transporter (T5, facelift 2009) Kombi 2.0 (116 Hp) L1H2? | 5, manual transmission |
| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Transporter |
| Generation | Transporter (T5, facelift 2009) Kombi |
| Modification (Engine) | 2.0 (116 Hp) L1H2 |
| Start of production | 2009 year |
| End of production | 2013 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 4-9 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC) | 13.6 l/100 km
17.3 US mpg 20.77 UK mpg 7.35 km/l |
| Fuel consumption (economy) - extra urban (NEDC) | 8.6 l/100 km
27.35 US mpg 32.85 UK mpg 11.63 km/l |
| Fuel consumption (economy) - combined (NEDC) | 10.4 l/100 km
22.62 US mpg 27.16 UK mpg 9.62 km/l |
| CO2 emissions (NEDC) | 243 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 - 100 km/h | 16.6 sec |
| Acceleration 0 - 62 mph | 16.6 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 15.8 sec |
| Maximum speed | 158 km/h 98.18 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 16.4 kg/Hp, 61 Hp/tonne |
| Weight-to-torque ratio | 11.2 kg/Nm, 89.4 Nm/tonne |
| Engine specs | |
| Power | 116 Hp @ 5200 rpm. |
| Power per litre | 58.5 Hp/l |
| Torque | 170 Nm @ 2700-4700 rpm. 125.39 lb.-ft. @ 2700-4700 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA113 / AXA |
| Engine displacement | 1984 cm3 121.07 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.5 mm 3.25 in. |
| Piston Stroke | 92.8 mm 3.65 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 5 l 5.28 US qt | 4.4 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.1 l 7.5 US qt | 6.25 UK qt |
| Space, Volume and weights | |
| Kerb Weight | 1901-2029 kg 4190.99 - 4473.18 lbs. |
| Max. weight | 2850 kg 6283.17 lbs. |
| Max load | 821-949 kg 1810 - 2092.19 lbs. |
| Trunk (boot) space - maximum | 6700 l 236.61 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4892 mm 192.6 in. |
| Width | 1904 mm 74.96 in. |
| Width including mirrors | 2283 mm 89.88 in. |
| Height | 2176 mm 85.67 in. |
| Wheelbase | 3000 mm 118.11 in. |
| Front overhang | 896 mm 35.28 in. |
| Rear overhang | 996 mm 39.21 in. |
| Ride height (ground clearance) | 201 mm 7.91 in. |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Approach angle | 21° |
| Departure angle | 17° |
| Ramp-over (brakeover) angle | 14° |
| Wading depth | 300 mm 11.81 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent coil spring, Transverse stabilizer, Trailing arm |
| Front brakes | Ventilated discs, 308x29.5 mm |
| Rear brakes | Ventilated discs, 294x22 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 215/65 R16 |
| Wheel rims size | 6.5J x 16 |
