| What is the body type, Volkswagen Tiguan II (facelift 2020)? | SUV, 5 Doors, 5 Seats |
|---|---|
| What is the fuel economy, Volkswagen Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 1.5 l/100 km 156.81 US mpg 188.32 UK mpg 66.67 km/l |
| How ECO is the car, Volkswagen Tiguan 1.4 TSI (245 Hp) eHybrid DSG? | 35 g/km CO2 Euro 6d-ISC-FCM |
| What is the range of pure electric driving, 1.4 TSI (245 Hp) eHybrid DSG? | 50 km 31.07 mi |
| What is electricity consumption, Volkswagen Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 15.2 kWh/100 km 24.46 kWh/100 mi 138 MPGe 6.6 km/kWh 4.1 mi/kWh |
| How fast is the car, 2020 Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 205 km/h | 127.38 mph 0-100 km/h: 7.5 sec 0-60 mph: 7.1 sec |
| How much power, Volkswagen Tiguan SUV 2020 1.4 TSI (245 Hp) eHybrid DSG? | 245 Hp, 400 Nm 295.02 lb.-ft. |
| What is the engine size, Volkswagen Tiguan SUV 2020 1.4 TSI (245 Hp) eHybrid DSG? | 1.4 l 1395 cm3 85.13 cu. in. |
| How many cylinders, 2020 Volkswagen 1.4 TSI (245 Hp) eHybrid DSG? | 4, Inline |
| What is the drivetrain, Volkswagen Tiguan II (facelift 2020) SUV 2020 1.4 TSI (245 Hp) eHybrid DSG? | Front wheel drive. PHEV (Plug-in Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2020 Volkswagen Tiguan SUV? | 4509 mm 177.52 in. |
| How wide is the vehicle, 2020 Volkswagen Tiguan SUV? | 1839 mm 72.4 in. |
| What is the curb weight, 2020 Volkswagen Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 1736 kg 3827.22 lbs. |
| What is the gross weight, 2020 Volkswagen Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 2350 kg 5180.86 lbs. |
| How much trunk (boot) space, 2020 Volkswagen Tiguan SUV? | 476 l 16.81 cu. ft. |
| How many gears, What type is the gearbox, 2020 Volkswagen Tiguan II (facelift 2020) 1.4 TSI (245 Hp) eHybrid DSG? | 6, automatic transmission DSG |
| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Tiguan |
| Generation | Tiguan II (facelift 2020) |
| Modification (Engine) | 1.4 TSI (245 Hp) eHybrid DSG |
| Start of production | November, 2020 year |
| End of production | June, 2022 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 1.5 l/100 km
156.81 US mpg 188.32 UK mpg 66.67 km/l |
| CO2 emissions (WLTP) | 35 g/km |
| Fuel consumption (economy) - combined (NEDC) | 1.8 l/100 km
130.67 US mpg 156.93 UK mpg 55.56 km/l |
| CO2 emissions (NEDC) | 42 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 - 100 km/h | 7.5 sec |
| Acceleration 0 - 62 mph | 7.5 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 7.1 sec |
| Maximum speed | 205 km/h 127.38 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 7.1 kg/Hp, 141.1 Hp/tonne |
| Weight-to-torque ratio | 4.3 kg/Nm, 230.4 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 13 kWh |
| Net (usable) battery capacity | 10.4 kWh |
| Battery technology | Lithium-ion (Li-Ion) |
| Battery weight | 130 kg 286.6 lbs. |
| Battery location | Below the floor, under the rear seats |
| All-electric range (WLTP) | 50 km 31.07 mi |
| All-electric range (NEDC) | 59 km 36.66 mi |
| Average Energy consumption (WLTP) | 15.2 kWh/100 km
24.46 kWh/100 mi 138 MPGe 6.6 km/kWh 4.1 mi/kWh |
| Average Energy consumption (NEDC) | 13.4 kWh/100 km
21.57 kWh/100 mi 156 MPGe 7.5 km/kWh 4.6 mi/kWh |
| Max speed (electric) | 130 km/h 80.78 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 115 Hp |
| Electric motor Torque | 330 Nm 243.4 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| System power | 245 Hp |
| System torque | 400 Nm 295.02 lb.-ft. |
| Internal combustion engine specs | |
| Power | 150 Hp @ 5000-6000 rpm. |
| Power per litre | 107.5 Hp/l |
| Torque | 250 Nm @ 1550-3500 rpm. 184.39 lb.-ft. @ 1550-3500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | DGEA |
| Engine displacement | 1395 cm3 85.13 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 74.5 mm 2.93 in. |
| Piston Stroke | 80 mm 3.15 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4 l 4.23 US qt | 3.52 UK qt |
| Engine oil specification | Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1736 kg 3827.22 lbs. |
| Max. weight | 2350 kg 5180.86 lbs. |
| Max load | 614 kg 1353.64 lbs. |
| Trunk (boot) space - minimum | 476 l 16.81 cu. ft. |
| Fuel tank capacity | 45 l 11.89 US gal | 9.9 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load with brakes (12%) | 1800 kg 3968.32 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4509 mm 177.52 in. |
| Width | 1839 mm 72.4 in. |
| Width including mirrors | 2099 mm 82.64 in. |
| Height | 1681 mm 66.18 in. |
| Wheelbase | 2680 mm 105.51 in. |
| Front track | 1576-1586 mm 62.05 - 62.44 in. |
| Rear (Back) track | 1567-1577 mm 61.69 - 62.09 in. |
| Minimum turning circle (turning diameter) | 11.5 m 37.73 ft. |
| Approach angle | 17.5° |
| Departure angle | 18.9° |
| Ramp-over (brakeover) angle | 16.5° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission DSG |
| Front suspension | Independent type McPherson, Transverse stabilizer |
| Rear suspension | Independent multi-link suspension, Transverse stabilizer |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 215/65 R17 |
| Wheel rims size | 7J x 17 |
