| What is the body type, Volkswagen Caravelle (T4, facelift 1996)? | Van, 4-5 Doors, 6-9 Seats |
|---|---|
| What is the fuel economy, Volkswagen Caravelle (T4, facelift 1996) 2.5 (115 Hp) Automatic? | 13 l/100 km 18.09 US mpg 21.73 UK mpg 7.69 km/l |
| How ECO is the car, Volkswagen Caravelle 2.5 (115 Hp) Automatic? | 312 g/km CO2 Euro 2 |
| How fast is the car, 1996 Caravelle (T4, facelift 1996) 2.5 (115 Hp) Automatic? | 160 km/h | 99.42 mph |
| How much power, Volkswagen Caravelle Van 1996 2.5 (115 Hp) Automatic? | 115 Hp, 200 Nm 147.51 lb.-ft. |
| What is the engine size, Volkswagen Caravelle Van 1996 2.5 (115 Hp) Automatic? | 2.5 l 2461 cm3 150.18 cu. in. |
| How many cylinders, 1996 Volkswagen 2.5 (115 Hp) Automatic? | 5, Inline |
| What is the drivetrain, Volkswagen Caravelle (T4, facelift 1996) Van 1996 2.5 (115 Hp) Automatic? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 1996 Volkswagen Caravelle Van? | 4789 mm 188.54 in. |
| How wide is the vehicle, 1996 Volkswagen Caravelle Van? | 1840 mm 72.44 in. |
| What is the curb weight, 1996 Volkswagen Caravelle (T4, facelift 1996) 2.5 (115 Hp) Automatic? | 1810 kg 3990.37 lbs. |
| What is the gross weight, 1996 Volkswagen Caravelle (T4, facelift 1996) 2.5 (115 Hp) Automatic? | 2730 kg 6018.62 lbs. |
| How much trunk (boot) space, 1996 Volkswagen Caravelle Van? | 5400 l 190.7 cu. ft. |
| How many gears, What type is the gearbox, 1996 Volkswagen Caravelle (T4, facelift 1996) 2.5 (115 Hp) Automatic? | 4, automatic transmission |
| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Caravelle |
| Generation | Caravelle (T4, facelift 1996) |
| Modification (Engine) | 2.5 (115 Hp) Automatic |
| Start of production | 1996 year |
| End of production | 2003 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Van |
| Seats | 6-9 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC) | 17.8 l/100 km
13.21 US mpg 15.87 UK mpg 5.62 km/l |
| Fuel consumption (economy) - extra urban (NEDC) | 10.3 l/100 km
22.84 US mpg 27.43 UK mpg 9.71 km/l |
| Fuel consumption (economy) - combined (NEDC) | 13 l/100 km
18.09 US mpg 21.73 UK mpg 7.69 km/l |
| CO2 emissions (NEDC) | 312 g/km |
| Fuel Type | Petrol (Gasoline) |
| Maximum speed | 160 km/h 99.42 mph |
| Emission standard | Euro 2 |
| Weight-to-power ratio | 15.7 kg/Hp, 63.5 Hp/tonne |
| Weight-to-torque ratio | 9.1 kg/Nm, 110.5 Nm/tonne |
| Engine specs | |
| Power | 115 Hp @ 4500 rpm. |
| Power per litre | 46.7 Hp/l |
| Torque | 200 Nm @ 2200 rpm. 147.51 lb.-ft. @ 2200 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | AET, APL, AVT |
| Engine displacement | 2461 cm3 150.18 cu. in. |
| Number of cylinders | 5 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 10:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | SOHC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 11.5 l 12.15 US qt | 10.12 UK qt |
| Space, Volume and weights | |
| Kerb Weight | 1810 kg 3990.37 lbs. |
| Max. weight | 2730 kg 6018.62 lbs. |
| Max load | 920 kg 2028.25 lbs. |
| Trunk (boot) space - maximum | 5400 l 190.7 cu. ft. |
| Fuel tank capacity | 80 l 21.13 US gal | 17.6 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 2000 kg 4409.25 lbs. |
| Permitted trailer load without brakes | 700 kg 1543.24 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4789 mm 188.54 in. |
| Width | 1840 mm 72.44 in. |
| Width including mirrors | 2175 mm 85.63 in. |
| Height | 1940 mm 76.38 in. |
| Wheelbase | 2920 mm 114.96 in. |
| Front track | 1589 mm 62.56 in. |
| Rear (Back) track | 1554 mm 61.18 in. |
| Front overhang | 968 mm 38.11 in. |
| Rear overhang | 901 mm 35.47 in. |
| Ride height (ground clearance) | 180 mm 7.09 in. |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Wading depth | 350 mm 13.78 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 4 gears, automatic transmission |
| Front suspension | Independent torsion bar, double wishbone, Transverse stabilizer |
| Rear suspension | Independent coil spring, Trailing arm |
| Front brakes | Disc |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/65 R15 |
| Wheel rims size | 6J x 15 |
