| What is the body type, Volkswagen Caddy Maxi Cargo V? | Minivan, 4-5 Doors, 2 Seats |
|---|---|
| What is the fuel economy, Volkswagen Caddy Maxi Cargo V 2.0 TDI (122 Hp) DSG? | 4.6 l/100 km 51.13 US mpg 61.41 UK mpg 21.74 km/l |
| How ECO is the car, Volkswagen Caddy 2.0 TDI (122 Hp) DSG? | 121 g/km CO2 Euro 6d-ISC-FCM |
| How fast is the car, 2020 Caddy Maxi Cargo V 2.0 TDI (122 Hp) DSG? | 184 km/h | 114.33 mph 0-100 km/h: 11.1 sec 0-60 mph: 10.5 sec |
| How much power, Volkswagen Caddy Minivan 2020 2.0 TDI (122 Hp) DSG? | 122 Hp, 320 Nm 236.02 lb.-ft. |
| What is the engine size, Volkswagen Caddy Minivan 2020 2.0 TDI (122 Hp) DSG? | 2.0 l 1968 cm3 120.09 cu. in. |
| How many cylinders, 2020 Volkswagen 2.0 TDI (122 Hp) DSG? | 4, Inline |
| What is the drivetrain, Volkswagen Caddy Maxi Cargo V Minivan 2020 2.0 TDI (122 Hp) DSG? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2020 Volkswagen Caddy Minivan? | 4853 mm 191.06 in. |
| How wide is the vehicle, 2020 Volkswagen Caddy Minivan? | 1855 mm 73.03 in. |
| What is the curb weight, 2020 Volkswagen Caddy Maxi Cargo V 2.0 TDI (122 Hp) DSG? | 1546 kg 3408.35 lbs. |
| What is the gross weight, 2020 Volkswagen Caddy Maxi Cargo V 2.0 TDI (122 Hp) DSG? | 2350 kg 5180.86 lbs. |
| How much trunk (boot) space, 2020 Volkswagen Caddy Minivan? | 3700 l 130.66 cu. ft. |
| How many gears, What type is the gearbox, 2020 Volkswagen Caddy Maxi Cargo V 2.0 TDI (122 Hp) DSG? | 7, automatic transmission DSG |
| General information | |
|---|---|
| Brand | Volkswagen |
| Model | Caddy |
| Generation | Caddy Maxi Cargo V |
| Modification (Engine) | 2.0 TDI (122 Hp) DSG |
| Start of production | 2020 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 2 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC, WLTP equivalent) | 5.6 l/100 km
42 US mpg 50.44 UK mpg 17.86 km/l |
| Fuel consumption (economy) - extra urban (NEDC, WLTP equivalent) | 4 l/100 km
58.8 US mpg 70.62 UK mpg 25 km/l |
| Fuel consumption (economy) - combined (NEDC, WLTP equivalent) | 4.6 l/100 km
51.13 US mpg 61.41 UK mpg 21.74 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 121 g/km |
| Fuel Type | Diesel |
| Acceleration 0 - 100 km/h | 11.1 sec |
| Acceleration 0 - 62 mph | 11.1 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 10.5 sec |
| Maximum speed | 184 km/h 114.33 mph |
| Emission standard | Euro 6d-ISC-FCM |
| Weight-to-power ratio | 12.7 kg/Hp, 78.9 Hp/tonne |
| Weight-to-torque ratio | 4.8 kg/Nm, 207 Nm/tonne |
| Engine specs | |
| Power | 122 Hp @ 2750-4250 rpm. |
| Power per litre | 62 Hp/l |
| Torque | 320 Nm @ 1600-2500 rpm. 236.02 lb.-ft. @ 1600-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA288 evo / DTRC |
| Engine displacement | 1968 cm3 120.09 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 81 mm 3.19 in. |
| Piston Stroke | 95.5 mm 3.76 in. |
| Compression ratio | 16:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.5 l 5.81 US qt | 4.84 UK qt |
| Engine oil specification |  Log in to see. |
| Engine systems | Start & Stop System Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1546 kg 3408.35 lbs. |
| Max. weight | 2350 kg 5180.86 lbs. |
| Max load | 804 kg 1772.52 lbs. |
| Trunk (boot) space - maximum | 3700 l 130.66 cu. ft. |
| Fuel tank capacity | 50 l 13.21 US gal | 11 UK gal |
| AdBlue tank | 15 l 3.96 US gal | 3.3 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1500 kg 3306.93 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4853 mm 191.06 in. |
| Width | 1855 mm 73.03 in. |
| Width including mirrors | 2100 mm 82.68 in. |
| Height | 1859 mm 73.19 in. |
| Wheelbase | 2970 mm 116.93 in. |
| Front overhang | 890 mm 35.04 in. |
| Rear overhang | 993 mm 39.09 in. |
| Ride height (ground clearance) | 159 mm 6.26 in. |
| Drag coefficient (Cd) | 0.30 |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Approach angle | 16.6° |
| Departure angle | 16.1° |
| Ramp-over (brakeover) angle | 13° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 7 gears, automatic transmission DSG |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Rigid axle suspension, Trailing arm, Coil spring |
| Front brakes | Ventilated discs, 312x25 mm |
| Rear brakes | Disc, 272x10 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16; 215/55 R17 |
| Wheel rims size | 6.5J x 16; 6.5J x 17 |
