| What is the body type, Hyundai Santa Fe IV (TM, facelift 2020)? | SUV, 5 Doors, 7 Seats |
|---|---|
| What is the fuel economy, Hyundai Santa Fe IV (TM, facelift 2020) 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 6.9 l/100 km 34.09 US mpg 40.94 UK mpg 14.49 km/l |
| How ECO is the car, Hyundai Santa Fe 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 157 g/km CO2 Euro 6d |
| How fast is the car, 2020 Santa Fe IV (TM, facelift 2020) 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 187 km/h | 116.2 mph 0-100 km/h: 8.9 sec 0-60 mph: 8.5 sec |
| How much power, Hyundai Santa Fe SUV 2020 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 230 Hp, 350 Nm 258.15 lb.-ft. |
| What is the engine size, Hyundai Santa Fe SUV 2020 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 1.6 l 1598 cm3 97.52 cu. in. |
| How many cylinders, 2020 Hyundai 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 4, Inline |
| What is the drivetrain, Hyundai Santa Fe IV (TM, facelift 2020) SUV 2020 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | Front wheel drive. FHEV (Full Hybrid Electric Vehicle). The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| How long is this vehicle, 2020 Hyundai Santa Fe SUV? | 4785 mm 188.39 in. |
| How wide is the vehicle, 2020 Hyundai Santa Fe SUV? | 1900 mm 74.8 in. |
| What is the curb weight, 2020 Hyundai Santa Fe IV (TM, facelift 2020) 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 1780-1906 kg 3924.23 - 4202.01 lbs. |
| What is the gross weight, 2020 Hyundai Santa Fe IV (TM, facelift 2020) 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 2580 kg 5687.93 lbs. |
| How much trunk (boot) space, 2020 Hyundai Santa Fe SUV? | 571 - 1649 l 20.16 - 58.23 cu. ft. |
| How many gears, What type is the gearbox, 2020 Hyundai Santa Fe IV (TM, facelift 2020) 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat? | 6, automatic transmission |
| General information | |
|---|---|
| Brand | Hyundai |
| Model | Santa Fe |
| Generation | Santa Fe IV (TM, facelift 2020) |
| Modification (Engine) | 1.6 T-GDI (230 Hp) Hybrid Automatic 7 Seat |
| Start of production | November, 2020 year |
| End of production | August, 2023 year |
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
| Body type | SUV |
| Seats | 7 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 6.9 l/100 km
34.09 US mpg 40.94 UK mpg 14.49 km/l |
| CO2 emissions (WLTP) | 157 g/km |
| Fuel consumption (economy) - urban (NEDC, WLTP equivalent) | 5.5 l/100 km
42.77 US mpg 51.36 UK mpg 18.18 km/l |
| Fuel consumption (economy) - extra urban (NEDC, WLTP equivalent) | 5.5 l/100 km
42.77 US mpg 51.36 UK mpg 18.18 km/l |
| Fuel consumption (economy) - combined (NEDC, WLTP equivalent) | 5.5 l/100 km
42.77 US mpg 51.36 UK mpg 18.18 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 126 g/km |
| Fuel Type | Petrol (Gasoline) |
| Acceleration 0 - 100 km/h | 8.9 sec |
| Acceleration 0 - 62 mph | 8.9 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 8.5 sec |
| Maximum speed | 187 km/h 116.2 mph |
| Emission standard | Euro 6d |
| Weight-to-power ratio | 7.7 kg/Hp, 129.2 Hp/tonne |
| Weight-to-torque ratio | 5.1 kg/Nm, 196.6 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 1.49 kWh |
| Battery technology | Lithium-polymer (LiPo) |
| Electric motor 1 | |
| Electric motor power | 60 Hp |
| Electric motor Torque | 264 Nm 194.72 lb.-ft. |
| Electric motor type | Synchronous |
| System power | 230 Hp |
| System torque | 350 Nm 258.15 lb.-ft. |
| Internal combustion engine specs | |
| Power | 180 Hp @ 5500 rpm. |
| Power per litre | 112.6 Hp/l |
| Torque | 265 Nm @ 1500-4500 rpm. 195.45 lb.-ft. @ 1500-4500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Smartstream / G4FP |
| Engine displacement | 1598 cm3 97.52 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 75.6 mm 2.98 in. |
| Piston Stroke | 89 mm 3.5 in. |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 4.8 l 5.07 US qt | 4.22 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 4.69 l 4.96 US qt | 4.13 UK qt |
| Engine systems | Start & Stop System Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1780-1906 kg 3924.23 - 4202.01 lbs. |
| Max. weight | 2580 kg 5687.93 lbs. |
| Max load | 674-800 kg 1485.92 - 1763.7 lbs. |
| Trunk (boot) space - minimum | 571-782 l 20.16 - 27.62 cu. ft. |
| Trunk (boot) space - maximum | 1649 l 58.23 cu. ft. |
| Fuel tank capacity | 67 l 17.7 US gal | 14.74 UK gal |
| Max. roof load | 100 kg 220.46 lbs. |
| Permitted trailer load with brakes (12%) | 1650 kg 3637.63 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 100 kg 220.46 lbs. |
| Dimensions | |
| Length | 4785 mm 188.39 in. |
| Width | 1900 mm 74.8 in. |
| Height | 1685 mm 66.34 in. |
| Wheelbase | 2765 mm 108.86 in. |
| Front track | 1646 mm 64.8 in. |
| Rear (Back) track | 1656 mm 65.2 in. |
| Ride height (ground clearance) | 176 mm 6.93 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 235/55 R19 |
| Wheel rims size | 7.5J x 19 |
