| What is the body type, Ford Transit Connect II Panel Van L1? | Minivan, 4-5 Doors, 2-3 Seats |
|---|---|
| What is the fuel economy, Ford Transit Connect II Panel Van L1 1.5 TDCi (75 Hp)? | 4.6 l/100 km 51.13 US mpg 61.41 UK mpg 21.74 km/l |
| How ECO is the car, Ford Transit Connect 1.5 TDCi (75 Hp)? | 120 g/km CO2 Euro 6 |
| How much power, Ford Transit Connect Minivan 2015 1.5 TDCi (75 Hp)? | 75 Hp, 220 Nm 162.26 lb.-ft. |
| What is the engine size, Ford Transit Connect Minivan 2015 1.5 TDCi (75 Hp)? | 1.5 l 1499 cm3 91.47 cu. in. |
| How many cylinders, 2015 Ford 1.5 TDCi (75 Hp)? | 4, Inline |
| What is the drivetrain, Ford Transit Connect II Panel Van L1 Minivan 2015 1.5 TDCi (75 Hp)? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2015 Ford Transit Connect Minivan? | 4418 mm 173.94 in. |
| How wide is the vehicle, 2015 Ford Transit Connect Minivan? | 1835 mm 72.24 in. |
| What is the curb weight, 2015 Ford Transit Connect II Panel Van L1 1.5 TDCi (75 Hp)? | 1382-1433 kg 3046.79 - 3159.22 lbs. |
| What is the gross weight, 2015 Ford Transit Connect II Panel Van L1 1.5 TDCi (75 Hp)? | 2005-2215 kg 4420.27 - 4883.24 lbs. |
| How much trunk (boot) space, 2015 Ford Transit Connect Minivan? | 2630 - 3700 l 92.88 - 130.66 cu. ft. |
| How many gears, What type is the gearbox, 2015 Ford Transit Connect II Panel Van L1 1.5 TDCi (75 Hp)? | 5, manual transmission |
| General information | |
|---|---|
| Brand | Ford |
| Model | Transit Connect |
| Generation | Transit Connect II Panel Van L1 |
| Modification (Engine) | 1.5 TDCi (75 Hp) |
| Start of production | 2015 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 2-3 |
| Doors | 4-5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC) | 5.2 l/100 km
45.23 US mpg 54.32 UK mpg 19.23 km/l |
| Fuel consumption (economy) - extra urban (NEDC) | 4.3 l/100 km
54.7 US mpg 65.69 UK mpg 23.26 km/l |
| Fuel consumption (economy) - combined (NEDC) | 4.6 l/100 km
51.13 US mpg 61.41 UK mpg 21.74 km/l |
| CO2 emissions (NEDC) | 120 g/km |
| Fuel Type | Diesel |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 18.4 kg/Hp, 54.3 Hp/tonne |
| Weight-to-torque ratio | 6.3 kg/Nm, 159.2 Nm/tonne |
| Engine specs | |
| Power | 75 Hp |
| Power per litre | 50 Hp/l |
| Torque | 220 Nm @ 1750-2000 rpm. 162.26 lb.-ft. @ 1750-2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Duratorq / XUGA |
| Engine displacement | 1499 cm3 91.47 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 73.5 mm 2.89 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | SOHC |
| Engine oil capacity | 6.2 l 6.55 US qt | 5.46 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6 l 6.34 US qt | 5.28 UK qt |
| Engine systems | Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1382-1433 kg 3046.79 - 3159.22 lbs. |
| Max. weight | 2005-2215 kg 4420.27 - 4883.24 lbs. |
| Max load | 623-782 kg 1373.48 - 1724.01 lbs. |
| Trunk (boot) space - minimum | 2630 l 92.88 cu. ft. |
| Trunk (boot) space - maximum | 3700 l 130.66 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 725 kg 1598.35 lbs. |
| Dimensions | |
| Length | 4418 mm 173.94 in. |
| Width | 1835 mm 72.24 in. |
| Width including mirrors | 2137 mm 84.13 in. |
| Height | 1861 mm 73.27 in. |
| Wheelbase | 2662 mm 104.8 in. |
| Front track | 1568 mm 61.73 in. |
| Rear (Back) track | 1584-1585 mm 62.36 - 62.4 in. |
| Front overhang | 878 mm 34.57 in. |
| Rear overhang | 878 mm 34.57 in. |
| Ride height (ground clearance) | 152 mm 5.98 in. |
| Minimum turning circle (turning diameter) | 11.7 m 38.39 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 300 mm |
| Rear brakes | Disc, 280 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16 |
| Wheel rims size | 6.5J x 16 |
