| What is the body type, Ford Transit Connect II Wagon L2? | Minivan, 5 Doors, 5-7 Seats |
|---|---|
| What is the fuel economy, Ford Transit Connect II Wagon L2 1.5 TDCi (75 Hp) Start-Stop? | 4.4 l/100 km 53.46 US mpg 64.2 UK mpg 22.73 km/l |
| How ECO is the car, Ford Transit Connect 1.5 TDCi (75 Hp) Start-Stop? | 115 g/km CO2 Euro 6 |
| How much power, Ford Transit Connect Minivan 2015 1.5 TDCi (75 Hp) Start-Stop? | 75 Hp, 220 Nm 162.26 lb.-ft. |
| What is the engine size, Ford Transit Connect Minivan 2015 1.5 TDCi (75 Hp) Start-Stop? | 1.5 l 1499 cm3 91.47 cu. in. |
| How many cylinders, 2015 Ford 1.5 TDCi (75 Hp) Start-Stop? | 4, Inline |
| What is the drivetrain, Ford Transit Connect II Wagon L2 Minivan 2015 1.5 TDCi (75 Hp) Start-Stop? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2015 Ford Transit Connect Minivan? | 4818 mm 189.69 in. |
| How wide is the vehicle, 2015 Ford Transit Connect Minivan? | 1835 mm 72.24 in. |
| What is the curb weight, 2015 Ford Transit Connect II Wagon L2 1.5 TDCi (75 Hp) Start-Stop? | 1466-1488 kg 3231.98 - 3280.48 lbs. |
| What is the gross weight, 2015 Ford Transit Connect II Wagon L2 1.5 TDCi (75 Hp) Start-Stop? | 2270 kg 5004.49 lbs. |
| How much trunk (boot) space, 2015 Ford Transit Connect Minivan? | 322 - 2761 l 11.37 - 97.5 cu. ft. |
| How many gears, What type is the gearbox, 2015 Ford Transit Connect II Wagon L2 1.5 TDCi (75 Hp) Start-Stop? | 5, manual transmission |
| General information | |
|---|---|
| Brand | Ford |
| Model | Transit Connect |
| Generation | Transit Connect II Wagon L2 |
| Modification (Engine) | 1.5 TDCi (75 Hp) Start-Stop |
| Start of production | 2015 year |
| End of production | 2018 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 5-7 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC) | 4.7-4.8 l/100 km
50.05 - 49 US mpg 60.1 - 58.85 UK mpg 21.28 - 20.83 km/l |
| Fuel consumption (economy) - extra urban (NEDC) | 4.3 l/100 km
54.7 US mpg 65.69 UK mpg 23.26 km/l |
| Fuel consumption (economy) - combined (NEDC) | 4.4 l/100 km
53.46 US mpg 64.2 UK mpg 22.73 km/l |
| CO2 emissions (NEDC) | 115 g/km |
| Fuel Type | Diesel |
| Emission standard | Euro 6 |
| Weight-to-power ratio | 19.5 kg/Hp, 51.2 Hp/tonne |
| Weight-to-torque ratio | 6.7 kg/Nm, 150.1 Nm/tonne |
| Engine specs | |
| Power | 75 Hp |
| Power per litre | 50 Hp/l |
| Torque | 220 Nm @ 1750-2000 rpm. 162.26 lb.-ft. @ 1750-2000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Duratorq / XUGA |
| Engine displacement | 1499 cm3 91.47 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 73.5 mm 2.89 in. |
| Piston Stroke | 88.3 mm 3.48 in. |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | SOHC |
| Engine oil capacity | 6.2 l 6.55 US qt | 5.46 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 6 l 6.34 US qt | 5.28 UK qt |
| Engine systems | Start & Stop System Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1466-1488 kg 3231.98 - 3280.48 lbs. |
| Max. weight | 2270 kg 5004.49 lbs. |
| Max load | 782-804 kg 1724.01 - 1772.52 lbs. |
| Trunk (boot) space - minimum | 322 l 11.37 cu. ft. |
| Trunk (boot) space - maximum | 2761 l 97.5 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Dimensions | |
| Length | 4818 mm 189.69 in. |
| Width | 1835 mm 72.24 in. |
| Width including mirrors | 2137 mm 84.13 in. |
| Height | 1840-1845 mm 72.44 - 72.64 in. |
| Wheelbase | 3062 mm 120.55 in. |
| Front track | 1568 mm 61.73 in. |
| Rear (Back) track | 1584 mm 62.36 in. |
| Front overhang | 878 mm 34.57 in. |
| Rear overhang | 878 mm 34.57 in. |
| Ride height (ground clearance) | 163 mm 6.42 in. |
| Minimum turning circle (turning diameter) | 12.5 m 41.01 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Coil spring, Torsion |
| Front brakes | Ventilated discs, 300x25 mm |
| Rear brakes | Disc, 280x11 mm |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 205/60 R16 |
| Wheel rims size | 6.5J x 16 |
