| What is the body type, Ford Transit Connect I (facelift 2009) Panel Van L2H2? | Minivan, 3-5 Doors, 2 Seats |
|---|---|
| What is the fuel economy, Ford Transit Connect I (facelift 2009) Panel Van L2H2 1.8 TDCi (90 Hp) DPF? | 6.1 l/100 km 38.56 US mpg 46.31 UK mpg 16.39 km/l |
| How ECO is the car, Ford Transit Connect 1.8 TDCi (90 Hp) DPF? | 162 g/km CO2 Euro 5 |
| How fast is the car, 2011 Transit Connect I (facelift 2009) Panel Van L2H2 1.8 TDCi (90 Hp) DPF? | 153 km/h | 95.07 mph 0-100 km/h: 17.4 sec 0-60 mph: 16.5 sec |
| How much power, Ford Transit Connect Minivan 2011 1.8 TDCi (90 Hp) DPF? | 90 Hp, 235 Nm 173.33 lb.-ft. |
| What is the engine size, Ford Transit Connect Minivan 2011 1.8 TDCi (90 Hp) DPF? | 1.8 l 1753 cm3 106.97 cu. in. |
| How many cylinders, 2011 Ford 1.8 TDCi (90 Hp) DPF? | 4, Inline |
| What is the drivetrain, Ford Transit Connect I (facelift 2009) Panel Van L2H2 Minivan 2011 1.8 TDCi (90 Hp) DPF? | Front wheel drive. Internal Combustion engine. The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| How long is this vehicle, 2011 Ford Transit Connect Minivan? | 4525 mm 178.15 in. |
| How wide is the vehicle, 2011 Ford Transit Connect Minivan? | 1795 mm 70.67 in. |
| What is the curb weight, 2011 Ford Transit Connect I (facelift 2009) Panel Van L2H2 1.8 TDCi (90 Hp) DPF? | 1432-1560 kg 3157.02 - 3439.21 lbs. |
| What is the gross weight, 2011 Ford Transit Connect I (facelift 2009) Panel Van L2H2 1.8 TDCi (90 Hp) DPF? | 2340 kg 5158.82 lbs. |
| How much trunk (boot) space, 2011 Ford Transit Connect Minivan? | 3700 - 4300 l 130.66 - 151.85 cu. ft. |
| How many gears, What type is the gearbox, 2011 Ford Transit Connect I (facelift 2009) Panel Van L2H2 1.8 TDCi (90 Hp) DPF? | 5, manual transmission |
| General information | |
|---|---|
| Brand | Ford |
| Model | Transit Connect |
| Generation | Transit Connect I (facelift 2009) Panel Van L2H2 |
| Modification (Engine) | 1.8 TDCi (90 Hp) DPF |
| Start of production | September, 2011 year |
| End of production | 2013 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 2 |
| Doors | 3-5 |
| Performance specs | |
| Fuel consumption (economy) - urban (NEDC) | 7.3 l/100 km
32.22 US mpg 38.7 UK mpg 13.7 km/l |
| Fuel consumption (economy) - extra urban (NEDC) | 5.4 l/100 km
43.56 US mpg 52.31 UK mpg 18.52 km/l |
| Fuel consumption (economy) - combined (NEDC) | 6.1 l/100 km
38.56 US mpg 46.31 UK mpg 16.39 km/l |
| CO2 emissions (NEDC) | 162 g/km |
| Fuel Type | Diesel |
| Acceleration 0 - 100 km/h | 17.4 sec |
| Acceleration 0 - 62 mph | 17.4 sec |
| Acceleration 0 - 60 mph (Calculated by Auto-Data.net) | 16.5 sec |
| Maximum speed | 153 km/h 95.07 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 15.9 kg/Hp, 62.8 Hp/tonne |
| Weight-to-torque ratio | 6.1 kg/Nm, 164.1 Nm/tonne |
| Engine specs | |
| Power | 90 Hp @ 4000 rpm. |
| Power per litre | 51.3 Hp/l |
| Torque | 235 Nm @ 1900 rpm. 173.33 lb.-ft. @ 1900 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | Duratorq / HCPA, P9PA, R3PA |
| Engine displacement | 1753 cm3 106.97 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 82.5 mm 3.25 in. |
| Piston Stroke | 82 mm 3.23 in. |
| Compression ratio | 19.4:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | SOHC |
| Engine oil capacity | 5.6 l 5.92 US qt | 4.93 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7 l 7.4 US qt | 6.16 UK qt |
| Engine systems | Particulate filter |
| Space, Volume and weights | |
| Kerb Weight | 1432-1560 kg 3157.02 - 3439.21 lbs. |
| Max. weight | 2340 kg 5158.82 lbs. |
| Max load | 780-908 kg 1719.61 - 2001.8 lbs. |
| Trunk (boot) space - minimum | 3700 l 130.66 cu. ft. |
| Trunk (boot) space - maximum | 4300 l 151.85 cu. ft. |
| Fuel tank capacity | 60 l 15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 735 kg 1620.4 lbs. |
| Dimensions | |
| Length | 4525 mm 178.15 in. |
| Width | 1795 mm 70.67 in. |
| Width including mirrors | 2044 mm 80.47 in. |
| Height | 1980 mm 77.95 in. |
| Wheelbase | 2912 mm 114.65 in. |
| Front track | 1505 mm 59.25 in. |
| Rear (Back) track | 1552 mm 61.1 in. |
| Front overhang | 861 mm 33.9 in. |
| Rear overhang | 751 mm 29.57 in. |
| Ride height (ground clearance) | 166 mm 6.54 in. |
| Minimum turning circle (turning diameter) | 11.9 m 39.04 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Transverse stabilizer, Leaf spring |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
| Wheel rims size | 6J x 15 |
